The ALB townhouse building kit is packaged/wrapped for sequence of assembly and includes:

  • 2 ¾” (70 mm) thick, pre-cut, numbered exterior walls
  • 2 ¾” (70 mm) thick, pre-cut, numbered interior walls
  • pre-cut, numbered gable components
  • pre-cut 4″ x 8″ (100mm x 200mm) glulam roof purlins
  • pre-cut, numbered 3/4″ (18mm) tongue & groove roof boards
  • pre-cut, numbered fascia boards
  • 6 interior doors 32″x80″ (812mm x 2040mm), hardware
  • 3 single wide wood windows 30″x39″ (765mm x 990mm)
  • 1 triple wide wood window 2295mm x 990mm (90″x39″)
  • 1 exterior door 36″x80″ (990mm x 2040mm) 1/2 glass tempered, multi-locking hardware
  • 1 exterior double door 61″ x 80″ (1550mm x 2040mm) 1/2 glass tempered, multi-locking hardware
  • deck posts, railing with vertical balustrades
  • 2 spare wall logs/spare roof boards
  • 3,300 – 8″ log screws to connect each row, gable components, purlins
  • Foundation size drawing
  • Stamped structural engineered drawings
